2-Piece Ball Valve 3/8 in Nominal FNPT End Style Brass Body Full Port Fluorocarbon Softgoods

2-Piece Ball Valve 3/8 in Nominal FNPT End Style Brass Body Full Port Fluorocarbon Softgoods

  • Manufacturer: NIBCO Inc.
  • Brand Name: NIBCO®
  • Part#: 257747
  • MPN: NL998H5
  • UPC: 039923276599
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Branch Availability

The NIBCO® brass ball valve with threaded end connections provides bubble-tight shut-off. The valve's PTFE seats and hard chrome-plated brass ball exhibit high chemical resistance properties. The valve is ideal for hot/cold water and gas applications. The NIBCO® brass ball valve provides ease of operation with quarter-turn (90 deg) open to close. The 2-Piece valve features threaded end connections for easy installation. Please refer to NIBCO® technical data sheet, valve selection guide and catalog for engineering and installation information. Choose NIBCO® ball valves for the most specified, versatile and economical valve option in commercial and residential applications. NIBCO® specialty valves are backed by a NIBCO® INC. 2-year limited warranty.

NIBCO® Ball Valve, 2-Piece, Series: T-FP-600A, 3/8 in Nominal, FNPT, 600 psi, Full Port, 0.39 in Orifice, Standard Lever Actuator, Brass Ball, 1.76 in Inlet to Outlet Length, 1.73 in Top to Inlet Center, Brass Body, Brass Stem and PTFE Ball Seat Trim, Fluorocarbon, Import

Actuator Type      :      Standard Lever
Ball Material      :      Brass
Body Material      :      Brass
Domestic/Import      :      Import
End Style      :      FNPT
Inlet to Outlet Length      :      1.76 in
Nominal Size      :      3/8 in
Orifice Size      :      0.39 in
Port Type      :      Full
Pressure Rating      :      600 psi
Series      :      T-FP-600A
Softgoods Material      :      Fluorocarbon
Top to Inlet Center      :      1.73 in
Trim Material      :      Brass Stem and PTFE Ball Seat
Type      :      2-Piece
  • Valve pressure rating 200 psi/13.8 bar non-shock cold working pressure
  • Blowout-proof stem
  • Fluorocarbon O-Ring
  • Use in U.S. drinking water applications is prohibited after January 3, 2014
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nibco_NG10406_Catalog.pdf
  • pdfSDS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nibco_0400015_SDS.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nibco_NJ998H6_Specification_Sheet.pdf
