3M™ 7000031666 Super 20 Printable Trimmed Film Tape, 60 yd L x 15-1/2 in W, 5 mil THK, Acrylic Adhesive, Epoxy Film Backing, White

3M™ epoxy film electrical tape super 20 is a 5 mil THK, high dielectric electrical tape. This flame-retardant tape is used as a coil cover, anchor, harnessing, banding, core, layer and crossover insulation. This tape is 600 V rated and withstands a temperature range of 32 to 311 deg F. 3M™ tape super 20 has an acrylic, pressure sensitive adhesive and is resistant to heat, oxidation, solvents and oils. This puncture-resistant tape has excellent electrical and handling properties. Highly conformable tape is tough and provides resistant to solder damage. It is suitable for use in wrapping relays, coils, transformers, bobbin wound sub fractional horsepower shaded pole motors and stick wound coils. UL listed and RoHS 2011/65/EU compliant.

3M™, 7000031666, Film Tape, Printable Trimmed, Series: Super 20, 60 yd Length, 15-1/2 in Width, 5 mil Thickness, White, 3 in Diameter Core, Acrylic Adhesive, Epoxy Film Backing, 30 in-oz Adhesion Strength, 600 V, 8000 V Dielectric Strength, 45 in-lb Tensile Strength, 311 deg F Maximum Operating, 32 deg F Minimum Operating, Specifications Met: ASTM D1000

• Flame-retardant and highly resistant to heat, oxidation, solvents and oils
• Temperature range, continuous operation not exceeding 155 degc (311 degf) per ul and csa listings
• No additional tools needed - no heat, moisture or other preparation is needed to apply adhesive

• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_054007_43191_Specification_Sheet.pdf
• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/3M_076308_62394_Catalog.pdf
