3M™ 7000049681 Double Linered Membrane Switch Spacer, 36 in L x 24 in W, 5 mil THK, 200MP Acrylic Adhesive, Polyester Film Backing, Clear
- Manufacturer: 3M
- Brand Name: 3M™
- Part#: 434967
- MPN: 7000049681
- UPC: 051115634710
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Sold As: 1/CS
-
Price:
- Add To Favorites
3M™ high performance acrylic adhesive 200MP is a popular choice and industry standard, for graphic attachment and general industrial joining applications. It provides outstanding adhesion to metal and high surface energy plastics. This adhesive provides some initial repositionability for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles and provides the assurance the switch will perform through difficult environmental conditions and millions of actuations.
CASE OF 50 3M 7000049681 MEMBRANE SWITCH SPACER DOUBLE LINERED 9045MP CLEAR 24 IN X 36 IN 5 MIL
| Adhesive Material | : | 200MP Acrylic |
| Backing Material | : | Polyester Film |
| Color | : | Clear |
| Length | : | 36 in |
| Liner Material | : | 94# Polycoated Kraft Paper |
| Maximum Operating Temperature | : | 400 deg F |
| Minimum Operating Temperature | : | -40 deg F |
| Specifications Met | : | ASTM D3330/D3654/D2370 |
| Thickness | : | 5 mil |
| Type | : | Double Linered |
| Width | : | 24 in |
- Ideal for circuit separation in switches until actuation, easy to die cut and process
- Excellent moisture and solvent resistance
- High temperature resistance
- High shear strength accommodates the stresses of repeated actuation
- Uv-resistant
- Not messy
- Easily die cuttable
- Adhesive resists oozing at slits and die-cuts for faster part processing
- Liners add dimensional stability for high-speed rotary die-cutting
- 2 mil 3M acrylic adhesive 200mp delivers excellent shear strength, resists slippage and edge lifting
- 1 mil polyester film carrier provides strength and stability
- Heavy 94 polycoated kraft (pck) liners deliver improved handling and lay-flat
