3M™ 7000148829 Insulated Butt Connector, 16 to 14 AWG Conductor, 1.02 in L, Seamless Barrel, Copper/Vinyl, Blue

3M™ 7000148829 Insulated Butt Connector, 16 to 14 AWG Conductor, 1.02 in L, Seamless Barrel, Copper/Vinyl, Blue

  • Manufacturer: 3M
  • Brand Name: 3M™
  • Part#: 437631
  • MPN: 7000148829
  • UPC: 054007018179
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

Secure your wires with this 3M™ Scotchlok™ Butt Connector. Its built-in wire stop ensures wires are positioned correctly for a smooth installation. This connector also has chamfered barrel ends for quick, easy wire insertion so you spend as little time as possible on this task. Its color coded blue to virtually eliminate confusion during and after installation, and its vinyl-insulated, seamless barrel provides a great fit for wires. Revitalizes pre-stripped stranded wires by providing an electrical connection via this butt connector, which is UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.

CASE OF 1000 3M 7000148829 SCOTCHLOK BUTT CONNECTOR VINYL INSULATED SEAMLESS MV14BCK 16-14AWG

Barrel Size      :      0.095 in ID x 0.3 in L
Barrel Type      :      Seamless
Color      :      Blue
Conductor Size      :      16 to 14 AWG
Dimensions      :      0.155 in OD
Length      :      1.02 in
Material      :      Copper/Vinyl
Temperature Rating      :      -40 to 221 deg F
Type      :      Standard
Voltage Rating      :      600 VAC
  • Uses chamfered barrel ends to provide fast, easy wire insertion from both ends and a built-in wire stop for correct positioning
  • Must be crimped at both ends
  • 0.031 in thickness
  • Crimp connection, vinyl insulation
  • Offers electrical connection to a pre-stripped end of a stranded wire
  • Vinyl-insulated, seamless barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Withstands a temperature range of -40 to 221 deg f (-40 to 105 deg c)
