Dixon Valve & Coupling 75-C-BR 257138
  1. pin-int

Dixon® 75-C-BR Type-C Cam and Groove Coupler, 3/4 in Nominal, Female Coupler x Hose Shank End Style, Brass, Domestic

Dixon® 75-C-BR Type-C Cam and Groove Coupler, 3/4 in Nominal, Female Coupler x Hose Shank End Style, Brass, Domestic

  • Manufacturer: Dixon Valve & Coupling
  • Brand Name: Dixon Valve & Coupling
  • Part#: 257138
  • MPN: 75-C-BR
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

Dixon® Cam and Groove Coupler, Type-C, Coupling Fitting/Connector, 3/4 in Nominal, Female Coupler x Hose Shank End Style, 3-3/4 in Length, 250 psi Pressure, Brass, Domestic

Domestic/Import      :      Domestic
End Style      :      Female Coupler x Hose Shank
Fitting/Connector Type      :      Coupling
Length      :      3-3/4 in
Material      :      Brass
Nominal Size      :      3/4 in
Pressure Rating      :      250 psi
Type      :      Type-C
  • 4-3/8 in open across cam arm
  • Precision machined to rigid tolerances
  • Stainless pins will not rust or bind, providing great strength and safety
  • Recess holds gasket firmly in place - ensures proper placement
  • Durable stainless steel cam arm pins
  • Supplied with safety clips
  • Produced to interchange with all product produced to commercial item description A-A-59326D
  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
  • Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
  • Do not use in connection with drinking water
  • Wash hands after handling
