Jomar Valve 100-133G 2-Piece Ball Valve With Handle, 1/2 in, MNPT x FNPT, Brass

Jomar Valve 100-133G 2-Piece Ball Valve With Handle, 1/2 in, MNPT x FNPT, Brass

  • Manufacturer: Jomar Valve
  • Brand Name: Jomar Valve®
  • Part#: 178569
  • MPN: 100-133G
  • UPC: 662527298300
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

Jomar Valve® Ball Valve, 2-Piece, 1/2 in Nominal, MNPT x FNPT End Style, 600 psi WOG Pressure, Full Port, 304 Stainless Steel Ball, 2-1/2 in Inlet to Outlet Length, 1-1/2 in Top to Inlet Center, Brass Body, 304 Stainless Steel Stem and PTFE Seat Trim, Buna-N/PTFE Softgoods

Ball Material      :      304 Stainless Steel
Body Material      :      Brass
End Style      :      MNPT x FNPT
Inlet to Outlet Length      :      2-1/2 in
Nominal Size      :      1/2 in
Port Type      :      Full
Pressure Rating      :      600 psi WOG
Softgoods Material      :      Buna-N/PTFE
Top to Inlet Center      :      1-1/2 in
Trim Material      :      304 Stainless Steel Stem and PTFE Seat
Type      :      2-Piece
  • Gland follower and single O-Ring stem design
  • Blow-out proof stem
  • 100% leak tested
  • Wetted surfaces contains less than 0.25 % lead content
  • 150 psi steam working pressure
  • Buna-N stem O-ring and PTFE packing
