Spears® 8097-040C 70074
  1. pin-int

Spears® 8097-040C Union, 4 in, Socket, SCH 80/XH, CPVC, EPDM O-Ring Seal, Domestic

Spears® 8097-040C Union, 4 in, Socket, SCH 80/XH, CPVC, EPDM O-Ring Seal, Domestic

  • Manufacturer: Spears Manufacturing
  • Brand Name: Spears®
  • Part#: 70074
  • MPN: 8097-040C
  • UPC: 054211858226
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

All CPVC schedule 80 fittings shall be produced by Spears® Manufacturing Company from CPVC materials, cell classification 23447 conforming to ASTM Standard D 1784. All injection-molded fittings through 12 in shall be manufactured in compliance to ASTM F 439 and Certified by NSF® International for use with potable water service. All 14 in through 24 in and fabricated fittings shall be produced in accordance with Spears® Specifications. All CPVC flanges shall be designed and manufactured to meet CL150 bolt pattern per ANSI Standard B16.5.

Spears® Union, Fitting/Connector Type: Union, 4 in Nominal, Socket, 5-1/8 in Length, SCH 80/XH, 235 psi, Molded, CPVC, EPDM O-Ring Seal, Gray, 73 deg F, Domestic

Color      :      Gray
Domestic/Import      :      Domestic
End Style      :      Socket
Fitting/Connector Type      :      Union
Length      :      5-1/8 in
Material      :      CPVC
Method of Manufacture      :      Molded
Nominal Size      :      4 in
Pressure Rating      :      235 psi
Schedule Rating      :      SCH 80/XH
Seal Material      :      EPDM O-Ring
Temperature Rating      :      73 deg F
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Spears_8097_040C_Specification_Sheet.pdf
  • linkVIDEO LINK http://youtu.be/Auyhm7YKQEICategories
