Spears® 897-040 Union, 4 in, Socket, SCH 80/XH, PVC, EPDM O-Ring, Domestic

Spears® 897-040 Union, 4 in, Socket, SCH 80/XH, PVC, EPDM O-Ring, Domestic

  • Manufacturer: Spears Manufacturing
  • Brand Name: Spears®
  • Part#: 51208
  • MPN: 897-040
  • UPC: 054211685341
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Branch Availability

All PVC SCH 80/XH fittings shall be produced by Spears® manufacturing company from PVC type I, cell classification 12454, conforming to ASTM Standard D1784. All injection molded PVC SCH 80/XH fittings shall be certified for potable water service by NSF® international manufactured in strict compliance to ASTM D2467. All fabricated fittings shall be produced in accordance with Spears® general specifications for fabricated fittings. All PVC flanges shall be designed and manufactured to meet CL150 bolt pattern per ANSI Standard B16.5 and rated for a maximum internal pressure of 150 psi, non-shock at 73 deg F.

Spears® Union, Fitting/Connector Type: Union, 4 in Nominal, Socket, 5-7/8 in Length, SCH 80/XH, 235 psi, Molded, PVC, EPDM O-Ring Seal, Gray, 73 deg F, 7-1/16 in OD, Domestic

Color      :      Gray
Dimensions      :      7-1/16 in OD
Domestic/Import      :      Domestic
End Style      :      Socket
Fitting/Connector Type      :      Union
Length      :      5-7/8 in
Material      :      PVC
Method of Manufacture      :      Molded
Nominal Size      :      4 in
Pressure Rating      :      235 psi
Schedule Rating      :      SCH 80/XH
Seal Material      :      EPDM O-Ring
Temperature Rating      :      73 deg F
