Trerice 450LFSS4504LA160SLF 450 Pressure Gauge
- Manufacturer: H.O. Trerice
- Brand Name: Trerice
- Part#: 450LFSS4504LA160SLF_
- MPN: 450LFSS4504LA160SLF
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price:
- Add To Favorites
The Trerice 450 Series Process Gauge is designed for the petrochemical and industrial process industries. This solid front, blow-out back gauge is noted for its fiberglass reinforced polypropylene turret case and screwed ring; its sturdy interior design; and its field liquid-fill capability (no kit required). The 450 Series can withstand the most rugged industrial applications, while maintaining precise accuracy. Wetted parts are bronze tube/brass socket, stainless steel, or Monel.
Trerice Pressure Gauge, Series: 450, 0 to 160 psi, 1/2 in MNPT, 4-1/2 in Dial Diameter, +/- 0.5 % Accuracy, Liquid Filled: Glycerin, 150 deg F, Lower Mount, Fiberglass Reinforced Polypropylene Case, 5.83 in Dia x 3.25 in D
| Accuracy | : | +/- 0.5 % |
| Connection Size | : | 1/2 in MNPT |
| Dial Diameter | : | 4-1/2 in |
| Dimensions | : | 5.83 in Dia x 3.25 in D |
| Liquid Filled | : | Glycerin |
| Material | : | Fiberglass Reinforced Polypropylene Case |
| Mounting Type | : | Lower |
| Pressure Range | : | 0 to 160 psi |
| Series | : | 450 |
| Temperature Rating | : | 150 deg F |
- Overload and underload stops
- Threaded fiberglass reinforced polypropylene ring
- Micro adjustable, black finished pointer
- 316L stainless steel tube and socket
- Acrylic window
- Fiberglass reinforced polypropylene turret case, solid front with blow-out back case
- Aluminum/white background with black graduations and markings dial face
- Stainless steel movement
