Trerice 500XB4502LA30/30 500X Vacuum Pressure Gauge
- Manufacturer: H.O. Trerice
- Brand Name: Trerice
- Part#: 500XB4502LA30/30_
- MPN: 500XB4502LA30/30
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price:
- Add To Favorites
The Trerice 500X Series Industrial Gauge is designed to withstand the most demanding applications of a variety of industries. This pressure gauge has a back flanged, cast aluminum case and stainless steel ring. Wetted parts are either bronze tube with Lead-Free (PBF) brass socket or stainless steel tube and socket.
Trerice Pressure Gauge, Vacuum, Series: 500X, 30 in Hg to 30 psi, 1/4 in, 4-1/2 in Dia Dial, +/- 0.5 % Accuracy, Graduations: 10/5, 250 deg F, Surface Mount, Cast Aluminum, Black, 5.88 in Dia x 2.06 in D
| Accuracy | : | +/- 0.5 % |
| Color | : | Black |
| Connection Size | : | 1/4 in |
| Dial Diameter | : | 4-1/2 in |
| Dimensions | : | 5.88 in Dia x 2.06 in D |
| Graduations | : | 10/5 |
| Material | : | Cast Aluminum |
| Mounting Type | : | Surface |
| Pressure Range | : | 30 in Hg to 30 psi |
| Series | : | 500X |
| Temperature Rating | : | 250 deg F |
| Type | : | Vacuum |
- Lower MNPT connection location
- Bronze tube and lead free (PBF) brass socket watted parts
