Victaulic® AG97030PFL 30-CR Reducing Lateral, 14 x 14 x 8 in, Grooved, Ductile Iron

Pipe of AWWA dimensions can be joined quickly and easily with the Victaulic® grooved piping method. Victaulic® products and recommendations conform to ANSI/AWWA C-606, Standard for Grooved and Shouldered Type Joints and CSA 242 M1980. The groove configuration for ductile (cast) pipe includes a large radius, eliminating sharp corners and stress concentration. This provides stronger beam load capability and higher working pressures for radius grooved systems than available with conventional flanged systems.

Victaulic® Reducing Lateral, Series: 30-CR, Fitting/Connector Type: Lateral, 14 x 14 x 8 in Nominal, Grooved, 350 psi, Cast, Ductile Iron, Orange Painted

• AWWA size fittings are supplied with rigid radius grooves in accordance with ANSI/AWWA C-606
• Fittings conform to ANSI 21.10/AWWA C-110 for center-to-end dimensions and AWWA C-153 or ANSI 21.10/AWWA C-110 for wall thicknesses
• Victaulic® can supply tapped fittings that meet ANSI B16.1 dimension locations

• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Victaulic_C040031GMX_Manual.pdf
• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Victaulic_A030030PF0_Specification_Sheet.pdf
• Technical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Victaulic_C040031GMX_Technical_Bulletin.pdf
